Semi-automatic pneumatic thermosealer


J Pack TSS125 Thermosealer


The TSS125 pneumatic semi-automatic thermosealer is a wheeled machine designed for MAP (Modified Atmosphere Packaging). All sealing parameters are customisable, and up to 10 different programmes can be stored. The machine is remarkably flexible: it is possible to choose between different sealing modes (sealing, vacuum and MAP) and the moulds can be customised. Thanks to the die-cut mould, the end result is a tray perfectly suited for supermarket shelves with an always fresh and inviting product.


TECHNICAL SPECIFICATIONS

Technical specifications TSS125
Dimensions 590 mm x 750 mm x 1,440 mm
Weight ca. 170 kg
Max. tray height 100 (optional 150) mm
Sealing plate size 420 mm x 280 mm
Max. film size Ø 250 mm x 470 mm
Cycles per minute 3 - 8
Air consumption 6 Nl/c
Pneumatic supply 6 - 8 bar
Gas supply 3 bar
Consumption ca. 3.5 kW
Power supply 380 V 3 P + N + T 16 A
