JPACK Neumaschinen

TSS102-F

Semi-automatic electric thermosealer

with Die-Cut

J Pack TSS102-F Thermosealer

Thanks to the small external dimensions and the personalized foil die-cut, the TSS102-F able to meet the needs of customers looking for a fast and functional semi-automatic tabletop machine. The end result is a sealed tray with an excellent aesthetic finish, perfect for supermarket shelves. The optional gas flushing helps maintain the freshness of the product.

TECHNICAL SPECIFICATIONS

Technical specifications	TSS102-F
Dimensions	295 mm x 450 mm x 550 mm
Weight	25 kg
Max. tray size	235 mm x 180 mm x 135 mm
Max. reel width and diameter	L= 210 / Ø 200 mm
Feeding	Electric
Tray loading and handling	Manual + Electric
Mould	Fixed with die-cut
Mould change	•
Customisable mould	•
Automatic film unwinding	•
Acoustic end-of-cycle buzzer	•
Partial and total cycle counter	•
Cycles per minute	3 - 8
Custom digital welding programmes	9
Power supply	220 V / 750 W

areas of application

Meat

Packaging of all kinds of meat.
Button
Fish

Preservation and packaging of all fish industry products.
Button
Vegetables

Packing of fresh and cooked vegetables.
Button
Fruit

Sealing of dried and fresh fruit.
Button
Cheese

Sealing of fresh, aged and creamy cheeses.
Button
Large-Scale Catering

Sealing of ready meals for large-scale food consumption.
Button
Deli Stores

Sealing of ready meals.
Button
Pasta

Packaging of fresh, filled, dry and pre-cooked pasta.
Button
Miscellaneous

Packaging of a wide array of products.
Button
Liquids

Special sealing of thick or liquid food.
